Multi-functional
Efficient
Easy to operate
|
Product Details:
|
| Type: | Wrapping Machine | Applicable Industries: | Manufacturing Plant |
|---|---|---|---|
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service | Local Service Location: | None |
| Showroom Location: | None | Condition: | New |
| Application: | Food, Chocolate | Packaging Type: | Film, Foil |
| Packaging Material: | Paper | Automatic Grade: | Semi-automatic |
| Driven Type: | Electric | Voltage: | 220V 50/60Hz |
| Dimension(L*W*H): | 2670*1520*2350mm | Weight: | 3000 KG |
| After-sales Service Provided: | Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service | Warranty: | 1 Year |
| Key Selling Points: | High-accuracy | Marketing Type: | New Product 2021 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Pressure Vessel, Gear, Motor, Engine, Bearing |
| Chocolate Size: | L:80-183 W:40-82 H:10-40 (mm) | Packing Speed: | 60-100pics/min (According To The Size) |
| Total Power: | 15.0KW | Power Supply: | 380V 50HZ 3PH (Can Be Customized) |
| Air Supply: | Pressure: 0.6MPa Flow: 0.6 M³/Min | Wrapper Material: | Foil,Wax Paper,BOPP.etc.(Must Be Easy To Fold) |
| Wrapper Width: | Inner Max.225mm, Outer Max.250mm | Wrapper Roller Size: | Inner Dia:76-90mm,Outer Dia≤300mm |
| Melting Gum Device: | Robatech(Switzerland) | Gross Weight: | 3000KGS |
| Port: | ShangHai / Shenzhen / Guangzhou |
